Working height : 33 m

Platform height : 33 m

Platform Size : 0.00 m x 0.00m

Platform Load : 250kg

Dimention (LxWxH) : 7.30m x 1.58m x 2.25m

Weight : 6200kg

Power : Electric




Categories: , , ,


The new articulated Falcon Spider Atrium Crawler Lift Falcon 330Z Vario, sets new standards. The
Falcon Spider Atrium Crawler Lift Falcon 330Z Vario is the highest articulated Z-boom on the market.
The Falcon Spider Atrium Crawler Lift Falcon 330Z Vario is an original Falcon Spider Atrium Lift with
market leading features. The Falcon Spider Atrium Lift was invented at first in the 1970’s, and developed
ever since. The Falcon Spider Atrium Crawler Lift Falcon 330Z Vario is very applicable in matters of:

  • Facility management
  • Atrium access
  • Narrow access
  • Best quality & safety
  • Double jib system
  • Easy transport & propelling
  • Low weight & ground pressure
  • Need for flexible outrigger
  • Limited setup space
  • Power – Bi-energy Hybrid


The two-arm over-center riser, four section telescopic aluminum boom, and 110° articulating jib together
offers the user a superior working envelope. Working height is 33 meters, reach 19 meters at an up and
over height of 11 meters.
The crawler undercarriage with variable width from 1.1 meters to 1.5 meters, offers impressive speed.
Further details on The Falcon Spider Atrium Crawler Lift Falcon 330Z Vario is mentioned below, or you
can click to download the full datasheet on this page also.



  • Automatic stability & outreach control
  • Computer controlled (can-bus)
  • Proportional control of all functions
  • Self-propelled 2 speed selection
  • Battery powered with charger 180 Ah
  • Jib-arm 110°
  • 375° turret rotation, with integrated stop
  • +/- 90° basket rotation
  • Ability to self-load onto trucks or trailers
  • Electronic checking of the power
  • system (PLC)
  • Manual pump system for emergency lowering
  • Variable width, hydraulic (1,1m -1,5m)
  • Minimum width only 1,10 m
  • Space for tools etc. in basket
  • Storage room in chassis with lock
  • Diesel engine, Kubota 3 cyl. 21,7 kw
  • Wireless remote control of all functions
  • 110v/220V AC power supply in the basket
  • Non marking crawlers
  • Individual setting of each outrigger



  • IDRC – Interactive Directional Remote Control
  • Hazard lights kit (strobe lights. working lamp)
  • Protection kit (enhanced shields/cover)
  • 400V AC direct powered electro motor
  • Autosetting / Leveling
  • Special outrigger footplate
  • Special colour
  • Service tool
  • Anti entrapment system
  • Cover
