HAULOTTE - VERTICAL MASTS - STAR 6
THE NEW STAR RANGE
Everything’s changed except the name!
More agile, more robust, more reliable than ever, easier to use and maintain…
The STAR range without jib is the ideal solution to carry out daily tasks aloft!
Working height : 5.8 m
Platform height : 3.8 m
Horizontal outreach : 0.4 m extension (option)
Lift capacity – inside : 230 kg (2 persons)
FEATURES :
- Go everywhere
- High precision driving & smoothness
- Comfort & agility
- Indoor / outdoor rated (versatile)
- Easy access to the platform
- Smart transportability & lifting
- With the best value for money
- Smart mast system
- Minimal maintenance & downtime
- Direct electric drive with brushless AC motors
- Easy access to components
- Haulotte Activ’Screen (onboard diagnostic)
- Haulotte Activ’Energy Management takes care of your batteries
STANDARD EQUIPMENT :
- 24 V electric drive brushless AC motors
- 2 x 12 V – 105 Ah batteries
- Battery charge indicator
- Haulotte Activ’Screen
- Fork lifting eyes
- Hoisting and lifting eyes
- Swing door entry gate
- Mobile potholes
- 2 front steering wheels
- 2 rear driving wheels
- Non marking tyres
- Brake release
- Hourmeter
- Horn
- Travel alarm
- Emergency stop
- Emergency hand pump
- 2 control stations at cage and ground level
- Mobile upper control box
- 2 towing hooks
- Protection baseboard
- Haulotte Activ’Energy Management: Smart CAN charger
OPTIONS :
- Platform extension deck + 0.4 m (height stowed: 1.8 m)
- Flashing light
- Power line in platform
- Ground-fault circuit interrupter 30 mA
- Hydraulic oil for cold countries
- Biodegradable oil
- Upper control box protection cover
- Fluorescent tube caddy
- Tool tray
- Telematics ready
- Haulotte Activ’Energy Management: automatic or manual battery waterfilling systems
