HAULOTTE - ARTICULATING BOOMS DIESEL - HA16 RTJ
Working height : 16 m
Platform height : 14 m
Lift capacity – inside : 230 kg (2 persons)
FEATURES :
- Performance & ease of use
- Industry leading working envelope with an outreach of 8.3 m
- Best lifting speed of 40 sec
- Fully proportional and simultaneous movements
- Minimized total cost of ownership
- Fully modular basket with upper control box cover
- Easy access to all components
- Haulotte Activ’Screen (on board diagnostic)
- Best comfort and safety feeling
- Haulotte Activ’Lighting System (option) for safe loading / unloading in conditions of low visibility
- Haulotte Activ’Shield Bar 2.0 (option)
- Haulotte Stop Emission System: automatically turns the engine off & on
STANDARD EQUIPMENT :
- 4 wheel drive
- 2 wheel steer
- Front oscillating axle (RTJ O) increases stability on uneven ground
- Permanent limited slip differential
- 230 kg (2 persons) load capacity
- 4 simultaneous movements for maximum productivity
- Rotating beacon
- Modular standard basket 1.83 m x 0.80 m, quick & easy to repair
- Drop bar entry gate
- Upper control box cover
- Tool tray
- AC power to platform (110 / 230 V)
- Embedded diagnostic system Haulotte Activ’Screen on lower control box, with color screen.
- Swing out engine tray for ease of maintenance
- Hour meter
- Low fuel level indicator (upper & lower control boxes)
- Engine pre-heater with light indicator
- Sound and light alarm for tilt and load
- 12 V battery / electrical control system
- Electric pump system and emergency descent
- Travel alarm
- Universal telematics plug
- Haulotte Stop Emission System
OPTIONS :
- Modular large basket 2.44 m x 0.91 m quick and easy to repair
- Lateral swing door entry gate
- Hydraulic generator Dynaset 3.5 Kw
- Air-line to platform 6.5 mm inner diameter
- Power to platform (female plug in the basket with or without circuit-breaker 30 mA)
- Working light
- Cold weather kit: -10°C / – 25°C
- Hot weather kit: hydraulic oil cooler + hydraulic oil
- Biodegradable hydraulic oil
- Large cured on solid rough terrain tires 1025 x 365
- Non-marking tires 14 x 17.5
- Haulotte Activ’Shield Bar 2.0
- Spark arrestor and electric one-way valve
- Battery cut-off
- Haulotte Activ’Lighting System
